Paper and Board Machines



Paper and Board Machines









Main features


Hydraulic headbox iNOVAFlow with optional auto-slice or dilution control for basis weight profile adjustment.


Fourdrinier with high drainage and formation efficiency with modular construction allowing future top wire installation.


Pick-up suction roll provides better efficiency and operational safety during the sheet transfer maintaining paper quality improving runnability and eliminating sheet breaks in this region.


SMART SHOE press with nip load up to 1300 kN/m that results on less steam consumption and improvement of sheet quality (physical tests)


Sheet stabilizer boxes improving machine runnability.


Dryer cylinders diameter: 1816 mm, manufactured in carbon steel plate designed for a working pressure up to 13 Bar and that features ZERO risk of explosion due to the excellent welding process applied on the steel plates and due to the steel tensile strength.


SMART SIZER for starch application can operate with solid contents up to 14% allowing costs reduction on the post-drying section and enabling the control of the starch volume application.


Hydraulic Pope Reel EH series with modular construction that allows future upgrades.


Hydraulic Winder designed for operating speeds up to 2500 m/min with regenerative brake motor on unwinding stand and automatic slitter positioning on slitting section


Machine brake systems for couch pit, press pit, size pit and reel pit
