MISTER PAPER – Indústria de Papel
MISTER PAPER, a company located in the city of Major Vieira, Santa Catarina State, Brazil, is celebrating its 8th anniversary with the acquisition of a new Tissue Paper Machine, the MP2.
With this investment, MISTER PAPER will now be able to produce high-quality premium paper, increasing even further its product portfolio.
The new machine - SMART ECO, supplied by HERGEN - is equipped with a Crescent Former, which provides excellent formation and CM basis weight profile, as well as great sheet softness. It also makes it possible to work at high speeds, while saving energy, fabrics and fibers.
Production with low energy consumption
Thanks to the steel Yankee Cylinder's extreme drying capacity, the SMART ECO machine enables the paper production with low energy consumption. Made of steel and with ribbed inner surface, the Smart Yankee Dryer allows greater heat exchange and, consequently, greater drying efficiency.
In this way, the machine works with a canopy hood, which simply extracts the water vapors that is generated by drying the paper process. The canopy hood uses just two small fans, with very low energy consumption.
This configuration makes it possible to extract the maximum performance from the machine.
Some project data
Production: 36 t/d double ply (15 g/m²) / 40 t/d towel paper (21 g/m²)
Sheet width at pope reel: up to 2,360 mm
Hydraulic Headbox model iNOVAFLOW
Crescent Former model HCF 920
Yankee Dryer Ø 3.660 mm, fabricated in steel with ribbed internal surface
Pneumatic Pope Reel with Column type Shaft Puller
HERGEN/MISTER PAPER
HERGEN wishes MISTER PAPER success in this new project and thanks them for the opportunity to take part in this important step for the company.
HERGEN TISSUE MACHINE
High-performance Tissue Machines up to 2.200 m/min
Drying and pressing concepts that deliver excellent cost effectiveness per ton of paper produced.
Flexible designs that allow for gradual upgrades starting from a basic model.
Proven engineering experience, with customized solutions that allow achieving performance very quickly and safely.
